S3T160
FuLl format. FuLly in control.
The S3T 160 brings tangential power to the widest roll formats. It delivers deliberate, precise cuts across 160 cm / 63-inch media, so large graphics, PPF and specialty films stay accurate from edge to edge.
Materials
Made for demanding wide format work
The S3T‑160 tangential cutter is the right fit when you produce:
Full width vehicle graphics and long body panels
Paint protection film (PPF) on wide rolls
Large decals and contour cut prints
Floor graphics and laminated wide format visuals
Specifications
What's in your S3T160
S3T160
Maximum media width
158cm / 62.2"
Cutting technology
Tangential cutting knife
Max cutting thickness
1.2 mm / 0.047"
Pinch rollers
4
Dimensions
Designed to pair with 63–65-inch printers and wide finishing lines
Cutting force
Up to 1kg for thicker or specialty materials
Print registration
OPOS mark reading for precise contour tracking
Compensation
OPOS XY technology to adjust cut path to follow potential deformations in the graphic
Connectivity
USB, Wi-Fi and Ethernet
Software
GoSign workflow management, compatible with over 50 RIP Softwares
Benefits
Why you'll love your S3T160
Wide format accuracy without compromise
The S3T‑160 keeps large graphics, long strips and complex shapes under tight control, even on demanding films.
Read more
Perfect for PPF and specialty films
Paint protection and other technical films benefit from controlled force and exact blade positioning.
Edges stay smooth. Corners stay true. Patterns fit as intended.
Read more
Detail that scales up
Fine shapes, small text and intricate paths remain consistent across the full 160 cm / 63-inch width, not just in the center of the roll.
Read more
Built for continuous production
The cutter absorbs natural roll behavior while maintaining stable tracking, so wide jobs run with less intervention.
Read more
One machine for your largest jobs
From wraps and panels to protection kits and floor graphics, the S3T‑160 brings tangential certainty to your widest, most visible applications.
Read more
Other S3T sizes
Looking for a different cutter?
S3T75
Maximum media width
74,2cm / 29.2"
Cutting technology
Tangential cutting knife
Max cutting thickness
1.2 mm / 0.047"
Pinch rollers
3
S3T120
Maximum media width
127cm / 50"
Cutting technology
Tangential cutting knife
Max cutting thickness
1.2 mm / 0.047"
Pinch rollers
3
S3T140
Maximum media width
135cm / 54"
Cutting technology
Tangential cutting knife
Max cutting thickness
1.2 mm / 0.047"
Pinch rollers
4
S3T160
Maximum media width
158cm / 62.2"
Cutting technology
Tangential cutting knife
Max cutting thickness
1.2 mm / 0.047"
Pinch rollers
4
